常見快恢復二極管型號參數
| 型號 | 品牌 | 額定電流 | 額定電壓 | 反向恢復二極管 | 封裝極性 |
| IN5817 | XXW | 1A | 20V | 10ns | |
| IN5819 | XXW | 1A | 40V | 10ns | |
| IN5819 | XXW | 1A | 40V | 10ns | |
| IN5822 | XXW | 3A | 40V | 10ns | |
| 21D-06 | XXW | 3A | 60V | 10ns | |
| SBR360 | XXW | 3A | 60V | 10ns | |
| C81-004 | XXW | 3A | 40V | 10ns | |
| 8TQ080 | XXW | 8A | 80V | 10ns | 單管 |
| MBR1045 | XXW | 10A | 45V | 10ns | 單管 |
| MBR1545CT | XXW | 15A | 45V | 10ns | 雙管 |
| MBR1654 | XXW | 16A | 45V | 10ns | 雙管 |
| 16CTQ100 | XXW | 16A | 100V | 10ns | 雙管 |
| MBR2035CT | XXW | 20A | 35V | 10ns | 雙管 |
| MBR2045CT | XXW | 20A | 45V | 10ns | 雙管 |
| MBR2060CT | MOT | 20A | 60V | 10ns | 雙管 |
| MBR20100CT | XXW | 20A | 100V | 10ns | 雙管 |
| 025CTQ045 | XXW | 25A | 45V | 10ns | 雙管 |
| 30CTQ045 | XXW | 30A | 45V | 10ns | 雙管 |
| C85-009* | XXW | 20A | 90V | 10ns | 雙管 |
| D83-004* | XXW | 30A | 40V | 10ns | 雙管 |
| D83-009* | XXW | 30A | 90V | 10ns | 雙管 |
| MBR4060* | XXW | 40A | 60V | 10ns | 雙管 |
| MBR30045 | XXW | 300A | 45V | 10ns | |
| MUR120 | XXW | 1A | 200V | 35ns | |
| MUR160 | XXW | 1A | 600V | 35ns | |
| MUR180 | XXW | 1A | 800V | 35ns | |
| MUR460 | XXW | 4A | 600V | 35ns | |
| BYV95 | XXW | 1.5A | 1000V | 250ns | |
| BYV27-50 | XXW | 2A | 55V | 25ns | |
| BYV927-100 | XXW | 2A | 100V | 25ns | |
| BYV927-300 | XXW | 2A | 300V | 25ns | |
| BYW76 | XXW | 3A | 1000V | 25ns | |
| BYT56G | XXW | 3A | 600V | 200ns | |
| BYT56M | XXW | 3A | 1000V | 100ns | |
| BYV26C | XXW | 1A | 600V | 100ns | |
| BYV26E | XXW | 1A | 1000V | 30ns | |
| FR607 | XXW | 6A | 1200V | 20ns | |
| MUR8100 | XXW | 8A | 200V | 200ns | 單管 |
| HFA15TB60 | XXW | 15A | 200V | 35ns | 單管 |
| HFA25TB60 | XXW | 25A | 200V | 35ns | 單管 |
| MUR30100 | XXW | 30A | 600V | 35ns | 單管 |
| MUR30120 | HAR | 30A | 1200V | 35ns | 單管 |
| MUR1620 | XXW | 16A | 200V | 35ns | 雙管 |
| MUR1620CT | XXW | 16A | 200V | 35ns | 雙管 |
| MUR1620P | XXW | 16A | 200V | 35ns | 雙管 |
| MUR1660CT | XXW | 16A | 600V | 35ns | 雙管 |
| HFA16TA600 | XXW | 16A | 600V | 35ns | 雙管 |
| MUR3030 | XXW | 30A | 300V | 35ns | 雙管 |
| MUR3040 | XXW | 30A | 400V | 35ns | 雙管 |
| MUR3060 | XXW | 30A | 600V | 35ns | 雙管 |
| HFA30TA600 | XXW | 30A | 600V | 35ns | 雙管 |
| MUR20040 | XXW | 200A | 400V | 35ns | 雙管 |
| B92M-02 | XXW | 20A | 200V | 35ns | 雙管 |
| C92-02 | XXW | 20A | 200V | 35ns | 雙管 |
| D92M-02 | XXW | 30A | 200V | 35ns | 雙管 |
| D92M-03 | XXW | 30A | 300V | 35ns | 雙管 |
| DSE130-06 | XXW | 30A | 600V | 35ns | 雙管 |
| DSE160-06 | XXW | 60A | 600V | 35ns | 雙管 |
FR/PFR系列快恢復二極管的主要參數
| 型號/參數 | 反向擊穿/ 電壓（V) |
最大正向 壓降（V) |
正向工作 電流（A） |
反向漏電 電流（μA） |
反向恢復 時間（μs) |
| FR-100/PFR-100 | 25 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-101/PFR-101 | 50 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-102/PFR-102 | 100 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-103/PFR-103 | 200 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-104/PFR-104 | 400 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-105/PFR-105 | 600 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-106/PFR-106 | 800 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-107/PFR-107 | 1000 | ≤1.8 | 1 | ≤10 | ≤0.85 |
| FR-150/PFR-150 | 25 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-151/PFR-151 | 50 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-152/PFR-152 | 100 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-153/PFR-153 | 200 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-154/PFR-154 | 200 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-155/PFR-155 | 400 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-156/PFR-156 | 600 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-157/PFR-157 | 800 | ≤1.8 | 1.5 | ≤10 | ≤0.85 |
| FR-200 | 25 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-201 | 50 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-202 | 100 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-203 | 200 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-204 | 400 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-205 | 600 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-206 | 800 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-207 | 1000 | ≤1.8 | 2 | ≤10 | ≤0.85 |
| FR-300 | 25 | ≤1.8 | 3 | ≤10 | ≤0.85 |
| FR-301 | 50 | ≤1.8 | 3 | ≤10 | ≤0.85 |
| FR-302 | 100 | ≤1.8 | 3 | ≤10 | ≤0.85 |
| FR-303 | 200 | ≤1.8 | 3 | ≤10 | ≤0.85 |
| FR-304 | 400 | ≤1.8 | 3 | ≤10 | ≤0.85 |
